Display: 240×64 dot-matrix LCD display
Digits: 6-digit resolution
Basic accuracy: 0.05%
Test signal frequency:
+ Range: 50Hz - 200kHz
+ Dots: 12000 Dots
Output impedance: 30Ω / 100Ω
AC Test level: 10mV - 2Vrms, 10mV steps
Test parameter: L, C, R, |Z|, D, Q, G, B, X, θd, θr, Vm, Im, △%
Measurement display range:
+ |Z|, R, X: 0.00001Ω - 99.9999MΩ
+ G, B: 0.00001μs - 99.9999s
+ C: 0.00001pF - 9.99999F
+ L: 0.00001μH - 99.9999kH
+ D: 0.00001 - 9.99999
+ Q: 0.00001 - 99999.9
+ θ(DEG): -179.999º - 179.999º
+ θ(RAD): -3.14159 - 3.14159
+ Δ%: -999.999% - 999.999%
Size (mm): 350(W)×122(H)×310(D)
Weight: 6.5 kg
