TOB TOB-TDT-JZ-1 Tap Density Tester With Three Testing Position (3samples,5-60min/time)

Voltage supply: AC 110V220V 50HZ/60HZ±10%

Power: 50W

Technical principle: Tap density refers to the powder in the container will be filled by the vibrated density

under specified conditions

Measure time: 5-60min/time, can test three samples a time

Vibration frequency: 60times/min

Oscillation Amplitude: 50mm

Measuring accuracy: ＜ ±1％, when test they drum automatically in a cycle of rotation angle,

ensuring the noodle was the level of the state,

so as to ensure the accuracy of measurement of the height of the noodle

Sample cylinder

Stainless steel material, Outside diameter : 19.7mm,

Inner diameter : 16.25mm, Height : 80mm, Volume : 16.6ml

Dimension(L*W*H): 400*280*280mm
