TOB TOB-LIC300 Battery Coating Machine (300mm Width)

Source voltage: AC 220V/110V, 50/60HZ

Suitable material width: Aluminum foil : 150-300mm, Copper foil : 150-300mm

Suitable material thickness: Aluminum foil : 11-30um, Copper foil : 9-30um

Suitable material diameter: 350mm

Suitable material weight: 300kg

Coating thickness: Cathode : 50-150um, Anode : 60-180um

Coating gap length: 5-500mm

Coating length:50-3500mm

Coating speed: Max 3m/min

Machine speed: 1.5-5m/min

Oven length: 2m/section, 3 section ovens

Coating accuracy

Hangover : ≤ ±1mm, according to the slurry performance

Head, Tail, Border: ≤ 5mm

Length error: ≤ ±0.75mm

Coating width error: ≤ ±0.5mm

Thickness error: -15-5um
