TLP HHY-1000F Hydraulic Crimping Head (35T; 30mm)

Output Force (ton): 35

Ram Stroke (mm): 30

Crimping Range (mm²): 240 – 1000

Crimping Dies (mm²): 400, 500, 630, 800, 1000

Crimp Pattern: Hexagonal type

Gross Weight (kg): 23.7

Packing Size (mm): 200 × 200 × 370

Characteristics:

For use in indoor and outdoor power distribution and transmission projects, splicing fittings, overhead and underground conductors.

●Yoke-type head design is solid and durable.

●Convenient handle makes handling and hoisting easier.

●Positive die locking mechanism holds dies firmly in place.

●Supplied with R2 3/8 male coupler and dust cap.

●Requires an external hydraulic pump with rated oil pressure of 700 bar.

●Single action cylinder with spring return.
