TLP HHK-8C Self-contained Hydraulic Knockout Puncher (11T; 22mm)

Output force: 11 ton

Stroke: 22 mm

Max thickness: 1.6 mm stainless steel / 3.2 mm mild steel

Punch range: 16–60 mm

Punch dies: Ø22, Ø27, Ø34, Ø43, Ø49, Ø60 mm

Machine weight: 11.5 kg

Packing size: 480 × 300 × 160 mm

Characteristics:

Punching capacity:

Stainless steel plate up to 1.6 mm thickness

Mild steel plate up to 3.2 mm thickness

Punching range: Ø16-60mm

●Fast, easy and simple to operate.

●Compact design for field use on construction sites and maintenance jobs.

●Robust and durable.

●Ram rotates 360° for greatest versatility.

●Sturdy plastic carry case
