Tinsley ZX75E Decade Resistance Box (RmaxΩ: 11111.1)

Reference and Nominal Temperatures

+ Reference Range: 20 ± 1.0 ºc

+ Nominal Range : 20 ± 10ºc

Reference and Nominal Relative Humidity

+ Reference Range: 40% ~ 60%

+ Nominal Range: 25% ~ 75%

Measuring Range and Step Resolution

+ RmaxΩ: 11111.1

+ RminΩ : 0.01

Accuracy In Percent (%) :

X1 MΩ : --

X100kΩ : --

X10 kΩ : --

X1 kΩ: ± 0.01

 x100Ω: ± 0.01

 x10Ω : ± 0.02

x1Ω : ± 0.02

X0.1Ω :  ± 0.05

X0.01Ω : ± 5.0

X0.001Ω: --

Residual Resistance : --

Power Ratings

+ Reference Power : 0.05 W

+ Nominal Power : 0.1 W

+ Ultimate Power : 0.2 W

Dimensions and Weights

+ Number of Decades : 6

+ Dimensions (mm) : 440 x 130 x 120

+ Weight (kg): 4.5

Datasheet
