THORLABS M365LP1‐C5 Collimated LED (UV; 385 nm; 435 mW; 43 mm; Nikon Eclipse)

Color: UV

Nominal Wavelength(a): 365 nm

Bandwidth (FWHM): 9 nm

Maximum Current (CW): 1700 mA

Forward Voltage: 4.0 V

Electrical Power (Max): 6800 mW

Emitter Size: 2.5 mm x 2.5 mm

Typical Lifetime: >10 000 h

Operating Temperature (Non-Condensing): 0 to 40 °C

Storage Temperature: -40 to 70 °C

Risk Group(b): RG3 – High Risk Group

***a. Value is approximate.

b. According to the standard IEC 62471:2006, Photobiological Safety of Lamps and Lamp Systems

Total Beam Power(a,b): 435 mW

Beam Diameter(a): 43 mm

Compatible Microscopes: Nikon Eclipse

***a. Values are approximate.

b. Measured at Maximum Current
