Thermofisher Eutech 1710 pH/mV bench meters (-2.00 to 18.00 pH)

pH

Range: -2.00 to 18.00 pH

Resolution: 0.1, 0.01 pH

Relative accuracy: ±0.01 pH ± 1 LSD

Calibration points: 1 to 5 points

Calibration method: Automatic buffer recognition with manual buffer entry option

Calibration pH buffer sets: USA (pH 1.68, 4.01, 7.00, 10.01, 12.45)

NIST (pH 1.68, 4.01, 6.86, 9.18 ,12.45)

Slope display: Yes

mV / ORP

Range: ±2000 mV

Resolution: 0.1 mV

Relative accuracy: ±0.2 mV or ±0.05 % of the reading, whichever is greater

Calibration points: 1 point

Offset adjustment: Up to ±250 mV

Temperature

Range: -5.0 to 105.0 ºC

Resolution: 0.1 ºC

Relative accuracy: ±0.3 ºC

Calibration points: 1 point

Offset adjustment: Up to ±5 ºC

Features

Display: 5” backlit LCD

Time and date: Yes

Time format: 12 hour AM/PM

Date format: Selectable, DD-MM-YYYY or MM-DDYYYY

Read types: Continuous, Auto-Read, Timed

Timed interval: 5 seconds to 60 minutes

Features - continued

Data log: 500 sets with time and date

Calibration log: Active pH, RmV, temperature with time and date

Calibration alarm: Yes, 1 to 168 hours or off

Sleep mode: Yes, optional

Self-test: Automatic with startup

Memory: Non-volatile

Input: BNC, ATC

Data output: Computer or printer

Data output format: CSV or print

Warranty: 3 years

Certifications: CE, cTUVus, FCC Class B, CES-001, KC, RCM

Enclosure: IP-54

Power: 100-240 VAC, 50-60Hz, 9 DC adapter, 1.3A

Dimensions (L x W x H): 198.3 mm x 155.2 mm x 61.7 mm

Weight: 700 grams

Environmental conditions

Environmental conditions: Indoors

Altitude: Up to 2,000 metres

Operating temperature: 5°C to 45°C

Operating relative humidity: 5 to 85%, non-condensing

Storage temperature: -20°C to 60°C

Storage relative humidity: 5 to 85%, non-condensing

Mains fluctuation: ±10% of range (100-240VAC)

Installation category: II

Pollution degree: 2

Protection class: III

Datasheet
