Texas Instruments UCC27311ADRCR Half-Bridge 120V 4A half-bridge driver with 8V UVLO

Shutdown: Shutdown

Fall Time: 5.5 ns

Rise Time: 7.2 ns

Logic Type: CMOS, TTL

Technology: SiC

Configuration: Non-Inverting

Mounting Style: SMD/SMT

Output Current: 4.5 A, 3.7 A

Number of Drivers: 2 Driver

Number of Outputs: 2 Output

Supply Voltage - Max: 17 V

Supply Voltage - Min: 8 V

Propagation Delay - Max: 42 ns

Operating Supply Current: 3 mA

Maximum Turn-On Delay Time: 17 ns

Maximum Turn-Off Delay Time: 17 ns

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
