Texas Instruments TMS320VC5510AZAV2 DSPs Fixed-Point Digital Signal Processors 24

Core: C55x

I/O Voltage: 3.3 V

Data RAM Size: 256 kB

Data ROM Size: 32 kB

Mounting Style: SMD/SMT

Number of Cores: 1 Core

Watchdog Timers: No Watchdog Timer

Instruction Type: Fixed Point

Moisture Sensitive: Yes

Program Memory Size: 352 kB

Supply Voltage - Max: 1.65 V

Supply Voltage - Min: 1.55 V

Maximum Clock Frequency: 200 MHz

Operating Supply Voltage: 1.6 V

Number of Timers/Counters: 2 Timer

L1 Cache Instruction Memory: 24 kB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: 0 C
