Texas Instruments SN74CBT34X245DBBR Digital Bus Switch ICs 32bit FET

Width: 6.1 mm

Height: 1.15 mm

Length: 17 mm

Logic Type: CMOS

Unit Weight: 265.100 mg

Organization: 8 x 1:1

Mounting Style: SMD/SMT

Number of Bits: 32 bit

On Resistance - Max: 7 Ohms

Supply Current - Max: 6 uA

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 4 V

Propagation Delay - Max: 250 ps

Operating Supply Voltage: 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
