Texas Instruments LP5036RJVR RGB LED Driver 36-channel I2C const ant current RGB LED

Dimming: With Dimming

Features: Constant Current, Current Control, I2C Control, Power Save Mode

Topology: Boost

Output Type: Constant Current

Unit Weight: 98.100 mg

Input Voltage: 2.7 V to 5.5 V

Mounting Style: SMD/SMT

Output Current: 35 mA

Output Voltage: 5.5 V

Development Kit: LP5036EVM

Number of Outputs: 36 Output

Number of Channels: 36 Channel

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.7 V

Operating Frequency: 29 kHz

Supply Current - Max: 10 mA

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
