Texas Instruments IWR1843ARQGALPR FMCW mmWave Sensor Single-chip 76-GHz t o 81-GHz industrial

Core: ARM Cortex R4F

Width: 15.1 mm

Height: 0.96 mm

Length: 15.1 mm

Technology: Si

Data RAM Size: 2 MB

ADC Resolution: 12 bit

Interface Type: GPIO, I2C, SPI, UART

Mounting Style: SMD/SMT

Number of I/Os: 47 I/O

Processor Series: IWR1843ARQ

Maximum Data Rate: 900 Mbps

Moisture Sensitive: Yes

Operating Frequency: 76 GHz to 81 GHz

Supply Voltage - Max: 1.32 V

Supply Voltage - Min: 1.14 V

Number of ADC Channels: 6 Channel

Maximum Clock Frequency: 200 MHz

Operating Supply Voltage: 1.2 V

Operating Temperature Range: - 40 C to + 125 C

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
