Texas Instruments INA2181A4IDSQR Current Sense Amplifiers 26V dual channel b i-directional 350kH A 595-INA2181A4IDSQT

Accuracy: 1 %

Gain V/V: 200 V/V

Shutdown: Shutdown

Gain Error: 0.1 %

Input Type: Differential

Output Type: High Side, Low Side

Mounting Style: SMD/SMT

SR - Slew Rate: 2 V/us

Development Kit: INA2181EVM

Number of Channels: 2 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.7 V

Ib - Input Bias Current: 75 uA

Maximum Input Resistance: 2.5 kOhms

Operating Supply Current: 500 uA

Vcm - Common Mode Voltage: 12 V

Ios - Input Offset Current: 50 nA

Output Current per Channel: 8 mA

Vos - Input Offset Voltage: 100 uV

GBP - Gain Bandwidth Product: 105 kHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

en - Input Voltage Noise Density: 40 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 100 dB
