Texas Instruments CC2538SF23RTQR Zigbee, 6LoWPAN, LR-WPAN IC RF ZigBee 802.15. 4 SoC hi per A 595-CC2538SF23RTQT
ModelCC2538SF23RTQR
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Core: ARM Cortex M3
Technology: Si
Sensitivity: - 97 dBm
Unit Weight: 200 mg
Output Power: 7 dBm
Mounting Style: SMD/SMT
Development Kit: CC2538DK
Maximum Data Rate: 250 kbps
Moisture Sensitive: Yes
Operating Frequency: 2.4 GHz
Program Memory Size: 256 kB
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2 V
Supply Current Receiving: 20 mA
Supply Current Transmitting: 24 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
