Texas Instruments ADC12DL3200ACF High Speed ADC 12-bit dual 3.2-GSP S or single 6.4-GSPS

Features: Ultra High Speed

Shutdown: No Shutdown

Input Type: Differential/Single-Ended

Resolution: 12 bit

Unit Weight: 2.547 g

Architecture: Folding Interpolating

Sampling Rate: 3.2 GS/s, 6.4 GS/s

Interface Type: LVDS, Parallel

Mounting Style: SMD/SMT

Reference Type: Internal

Development Kit: ADC12DL3200EVM

Power Consumption: 3.15 W

Moisture Sensitive: Yes

Number of Channels: 1 Channel/2 Channel

Number of Converters: 2 Converter

Analog Supply Voltage: 1.1 V, 1.9 V

Digital Supply Voltage: 1.1 V, 1.9 V

FPBW - Full Power Bandwidth: 8 GHz

INL - Integral Nonlinearity: 1.6 LSB

SNR - Signal to Noise Ratio: 57.8 dB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

DNL - Differential Nonlinearity: 0.3 LSB

ENOB - Effective Number of Bits: 9 Bit

SFDR - Spurious Free Dynamic Range: 70 dB

SINAD - Signal to Noise and Distortion Ratio: 56 dB
