Texas Instruments 66AK2H06DAAW2 DSPs High performance mul ticore DSP+Arm - 2x

Core: ARM Cortex A15, C66x

I/O Voltage: 0.85 V, 1 V, 1.35 V, 1.5 V, 1.8 V, 3.3 V

Unit Weight: 21.223 g

Data ROM Size: 128 kB, 256 kB

Interface Type: Ethernet, I2C, PCIe, SPI, UART, USB

Mounting Style: SMD/SMT

Number of I/Os: 32 I/O

Development Kit: EVMK2H

Number of Cores: 6 Core

Watchdog Timers: Watchdog Timer

Instruction Type: Fixed/Floating Point

Processor Series: C66x, ARM CorePacs

Moisture Sensitive: Yes

L1 Cache Data Memory: 2 x 32 kB, 4 x 32 kB

Supply Voltage - Max: 1.05 V

Supply Voltage - Min: 950 mV

Maximum Clock Frequency: 1.2 GHz, 1.2 GHz

Operating Supply Voltage: 800 mV to 1.1 V, 950 mV, 950 mV

Number of Timers/Counters: 14 Timer

L1 Cache Instruction Memory: 2 x 32 kB, 4 x 32 kB

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
