Testex TF128 Moisture Management Tester

Weight: 22 kg

Dimensions: 320 x 200 x 320 mm(L x W x H)

Interface: USB 1.1 / 2.0

Power Supply: 110 V ~ 230 V 50 Hz / 60 Hz 0.5 A

Operation Temp & R.H.: 18°C to 40°C, 20% to 80% (non-condensing)

Pump on Time: 20 sec

Test Solution: Conductivity - 16 ms ± 0.2 ms

Upper Weight: 4.65 N ± 0.05

Standards: AATCC 195

Moisture Management Tester, is to measure the dynamic liquid transport properties of textiles such as knitted and woven fabrics in three dimensions.

Absorption Rate - Moisture absorbing time of the fabric’s inner and outer surfaces. One-way Transportation Capability – Liquid moisture one-way transfer from fabric’s inner surface to outer surface.

Spreading / Drying Rate – Speed of liquid moisture spreading on fabric’s inner and outer surfaces

MMT permits the measurement of the following indexes

Wetting Time Top / Bottom (WTT / WTB)

Absorption Rate Top / Bottom (TAR / BAR)

Maximum Wetted Radius Top / Bottom (MWRT / MWRB)

Spreading Speed Top / Bottom (TSS / BSS)

Accumulative One-Way Transport Capacity (R)

Overall Moisture Management Capacity (OMMC)
