Tekbox TBJT02 Injection Transformer (1 Hz – 7 MHz)

Termination resistor: 5 Ω

Fuse: 100 mA (Littlefuse 0451.100MRL); secondary (output) side

Turns ratio: 1:1

Characterized freq. range: 1 Hz to 100 MHz

Usable frequency range: 1 Hz – 7 MHz

3 dB frequency range: 2 Hz – 3 MHz typ

Insertion loss (S21): 16 dB typ

Capacitance: 310 pF @ 1 Khz; primary to secondary winding

DC saturation current: 12 mA

Max. voltage rating: 600V CAT II; primary to secondary winding

Input connector: 50 Ω BNC female,

Output connector: 4 mm safety banana jacks, 20 mm spacing

Operating temp. range: 0°C – 60°C

Enclosure dimensions: 70 mm x 60 mm x 140 mm

Weight: 300 g
