TDK-Lambda PXD-M30-24WS24 Isolated 30W 9-36VDCin 24Vout 1.25A

Width: 25.4 mm (1 in)

Height: 10.16 mm (0.4 in)

Length: 50.8 mm (2 in)

Industry: Medical, Industrial

Dimensions: 50.8 mm x 25.4 mm x 10.2 mm

Output Power: 30 W

Input Voltage: 9 V to 36 V

Mounting Style: Through Hole

Isolation Voltage: 5 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 1.25 A

Output Voltage-Channel 1: 24 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
