TDK-Lambda ICH12012A007V-007-R Non-Isolated / PoL 12Vin 0.7-5.5Vout 12A Neg Log (LGA)

Width: 12.2 mm (0.48 in)

Height: 8.5 mm (0.335 in)

Length: 12.2 mm (0.48 in)

Industry: Industrial

Output Type: DC

Unit Weight: 80 g

Output Power: 85 W

REACH - SVHC: Details

Mounting Style: SMD/SMT

Number of Outputs: 1 Output

Moisture Sensitive: Yes

Input Voltage - Max: 14 V

Input Voltage - Min: 4.5 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 12 A

Output Voltage-Channel 1: 700 mV to 8.5 V

Maximum Operating Temperature: + 115 C

Minimum Operating Temperature: - 40 C
