| Bar diameter setting range | φ6mm~50mm | |
| Measuring range of different steel bar diameter | ||
| Rebar diameter(mm) | Min.(mm) | Max(mm) |
| φ6~Φ8 | 1~60 | 5~120 |
| Φ10~Φ20 | 1~80 | 5~160 |
| ≥Φ22 | 1~120 | 5~210 |
| Error range(mm) | Min(mm) | Max(mm) |
| ±1 | 1~80 | 5~80 |
| ±2 | 81~120 | 81~120 |
| ±4 | \ | 121~210 |
| Applicable range of diameter estimation | φ6mm~50mm | |
| The maximum error of diameter estimation | ±1 | |
| Distance accuracy | ±1mm | |
| Scanning mode | Regular scan, rule scan, grid scan, profile scan, fine scan, image scan | |
| Power supply mode | Built-in large-capacity lithium battery | |
| Working temperature | -10℃~+50℃ | |
| Size | 219mm×92mm×106mm | |
| Weight | 0.6kg |
