Taoglas PCUWB01.01.0500G Passive Antenna FR4 PCB WIDEBAND ANTENNA

Gain: 7.5 dBi, 4.1 dBi, 4.1 dBi

Width: 30 mm

Height: 10 mm

Length: 36 mm

IP Rating: IP67

Impedance: 50 Ohms

Cable Type: TGC-200

Application: Precision Surveying, Smart Home, Entertainment Systems, Indoor Position Location, Tracking Application

Unit Weight: 50 g

Cable Length: 0.5 m

Polarization: Linear

Power Rating: 5 W

Mounting Style: Adhesive Mount

Number of Bands: 3 Band

Center Frequency: 4 GHz, 7.1 GHz, 9.25 GHz

Mechanical Style: Module

Maximum Frequency: 10.3 GHz

Minimum Frequency: 3.1 GHz

Termination Style: Connector

Protocol - Sub GHz: UWB

Antenna Connector Type: SMA Male

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
