TAITEC S-BOX×10αII Culture Controller For Bioreactor (0.00 ~ 14.00 [pH]; 0.00 ~ 20.00 [mg/L]; 0.00 ~ 20.00 [mL/min])

Display range/accuracy:

pH: 0.00 to 14.00 [pH]

DO (Dissolved oxygen): 0.00 to 20.00 [mg/L]

FL (O2flow rate): 0.00 to 20.00 [mL/min]

Display accuracy: F.S±0.5 [%]

Setting range:

pH (Hydrogen ion concentration): 0.00 to 14.00 [pH]

DO: 0.00 to 10.00 [mg/L]

FL (O2 flow rate): 0.00 to 20.00 [mL/min]

Control output:

pH: ON/OFF control

DO: O2 addition/subtraction step control, O2 and N2 ON/OFF control, O2PI control (slope set method: time, %)

FL: PI control (slope set method: time, %)

Data output:

pH/DO/FL/Mixing frequency:

With data logger DC 0 - 5 [V]

*Load factor can be put out. (optional), Accuracy: F.S±0.5 [%]

Temperature:

With data logger DC 1 - 5 [V], Accuracy: F.S±0.5 [%]

Casing: SUS304 (no coating), indoor type, non-drip proof, non-explosion proof specification

Installation: Indoor tabletop type

Outer dimensions/weight: W350×H530×D400 [mm]・approx. 15[kg]

Environment conditions: Temperature: 5 to 45 [℃]

Humidity: 20 - 85% RH (with no condensate)

Sensors:

Standard accessories: Mettler Toledo company Polarographic DO sensor/pH sensor

Option: Automatic System Research Co., Ltd. Optical DO sensor

Power supply: AC100 [V] 50/60[Hz] electrical outlet × 2 (for controller unit and recorder)

Utilities:

N2: Flow rate 50 [mL/min] or lower Supply pressure 0.2 [MPa]

O2: Flow rate 20 [mL/min] or lower, supply pressure 0.2 [MPa]

CO2: Flow rate 50 [mL/min] or lower, supply pressure 0.2 [MPa]

AIR: Flow rate 150 [mL/min] or lower, supply pressure 0.2 [MPa]

*Connection port φ6 tube one-touch joint

*All of O₂, CO₂, and AIR must be dry gases that do not contain corrosive components, dust, and oil mist.
