Size: DN6~DN2800
Medium: Conductive liquid, slurry
Medium Temperature: E grade∠60℃.H grade∠180℃
Conductivity:≥5 u S/cm
Accuracy:±0.25% . ±0.5%
Repeatability: ±0.1%. ±0.17%
Rated Pressure: 0.6, 1.0, 1.6, 2.5, 4.0, 6.4 MPa (or specified by customer)
Display: Instantaneous flow rate, total flow, velocity, flowrate percentage with backlight
Signal Output: 4-20mA current output, pulse output, RS-485, Hart.
Power Supply: AC:85V~265V, DC:18V~38V
Velocity:0.05~12m/s ( 0.1~15m/s as required )
Liner: PU(DN25~DN500)/ F4(PTFE) (DN25~DN1600)/
F46(FEP) (DN10~DN200)/ PFA (DN10~30)
Flowing Direction: Forward, Reverse
Electrode Material: 316L, Pt, Ta, Ti, HB, HC, WC
Electrode Number: 3~6 pcs
Ambient: Temperature: -30~+60℃, Humidity: ＜90%
Protocal: RS-485/ Hart
