STMicroelectronics TSU112IYST Operational Amplifiers Nanopower (900 nA) high accuracy (150 uV) 5V CMOS Auto Op-Amp

Shutdown: No Shutdown

Qualification: AEC-Q101

Mounting Style: SMD/SMT

SR - Slew Rate: 3 mV/us

Number of Channels: 2 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1.5 V

Ib - Input Bias Current: 10 pA

Operating Supply Current: 840 nA

Ios - Input Offset Current: 10 pA

Output Current per Channel: 5 mA

Vos - Input Offset Voltage: 150 uV

GBP - Gain Bandwidth Product: 9 kHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

en - Input Voltage Noise Density: 220 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 99 dB
