STMicroelectronics TS331ICT Analog Comparators Micropower 20uA 1.6V to 5V RtoR

Shutdown: No Shutdown

Output Type: Open Drain

Unit Weight: 20 mg

Response Time: 210 ns

Mounting Style: SMD/SMT

Comparator Type: Differential

Reference Voltage: No

Number of Channels: 1 Channel

Supply Voltage - Max: 5 V

Supply Voltage - Min: 1.6 V

Propagation Delay Time: 210 ns

Ib - Input Bias Current: 40 nA

Low Level Output Current: 30 mA

Operating Supply Current: 20 uA

Operating Supply Voltage: 1.6 V to 5 V

High Level Output Current: 47 mA

Vcm - Common Mode Voltage: - 300 mV to 300 mV

Ios - Input Offset Current: 100 nA

Output Current per Channel: 22 mA

Vos - Input Offset Voltage: 5 mV

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
