STMicroelectronics TDA7498LTR 2-Channel Stereo 80W and 80W Dual BTL Class-D Audio Amp

Gain: 25.6 dB, 31.6 dB, 35.1 dB, 37.6 dB

Class: Class-D

Input Type: Differential

Unit Weight: 480 mg

Output Power: 80 W

Mounting Style: SMD/SMT

THD plus Noise: 0.1 %

Moisture Sensitive: Yes

Number of Channels: 2 Channel

Supply Voltage - Max: 36 V

Supply Voltage - Min: 14 V

Audio - Load Impedance: 6 Ohms

Pd - Power Dissipation: 16 W

Operating Supply Current: 40 mA

Operating Supply Voltage: 44 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
