STMicroelectronics STM32H7S7A8I6 ARM Microcontrollers High-performance & DSP DP-FPU Arm Cortex-M7 MCU 64KB Flash 620KB SRAM 550MHz CPU

Core: ARM Cortex M7

Unit Weight: 65 mg

Data RAM Size: 620 kB

Data RAM Type: SRAM

ADC Resolution: 12 bit

Data Bus Width: 32 bit

Interface Type: CAN, I2C, SPI, USART, USB

Mounting Style: SMD/SMT

Number of I/Os: 117 I/O

Watchdog Timers: Watchdog Timer, Windowed

Moisture Sensitive: Yes

Program Memory Size: 64 kB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 1.71 V

Number of ADC Channels: 17 Channel

Maximum Clock Frequency: 600 MHz

Operating Supply Voltage: 1.71 V to 3.6 V

Number of Timers/Counters: 11

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
