STMicroelectronics SPIRIT1QTR Wi-Fi Low Data Rate 1GHz 1 to 800KHz Trans

Technology: Si

Sensitivity: 118 dBm

Unit Weight: 123 mg

Output Power: 11 dBm

Interface Type: SPI

Mounting Style: SMD/SMT

Frequency Range: 150 MHz to 174 MHz, 300 MHz to 348 MHz, 387 MHz to 470 MHz, 779 MHz to 956 MHz

Maximum Data Rate: 500 kbps

Modulation Format: 2-FSK, ASK, GFSK, GMSK, MSK, OOK

Moisture Sensitive: Yes

Number of Receivers: 1

Supply Current - Max: 400 uA

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 1.8 V

Number of Transmitters: 1

Supply Current Receiving: 9 mA

Maximum Operating Frequency: 10 MHz

Supply Current Transmitting: 21 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
