STMicroelectronics SD4933 RF Power MOSFET RF Trans 200V 300W 24 dB at 30 MHz

Gain: 24 dB

Technology: Si

Output Power: 300 W

Configuration: Single

Mounting Style: SMD/SMT

Operating Frequency: 100 MHz

Transistor Polarity: N-Channel

Pd - Power Dissipation: 648 W

Vgs - Gate-Source Voltage: + 20 V

Id - Continuous Drain Current: 40 A

Maximum Operating Temperature: + 150 C

Forward Transconductance - Min: 8 S

Vds - Drain-Source Breakdown Voltage: 200 V
