Stewart Connector SS-60400-006 Modular Modular Jack Vertical CAT6 SealJack without LEDs M3 X 0.5 Threads

Gender: Jack (Female)

IP Rating: IP67

Shielding: Shielded, Flange

USOC Codes: RJ45

Application: 1G/10G Base-T

Configuration: 1x1

Mating Cycles: 750 Cycle

Tab Direction: Tab Down

Mounting Angle: Straight

Mounting Style: Through Hole

Contact Plating: Gold

Number of Ports: 1 Port

Contact Material: Copper Alloy

Termination Style: Solder

Mounting Direction: Vertical

Number of Contacts: 8 Contact

Flammability Rating: UL94 V-0

Number of Positions: 8 Position

Performance Category: Cat 6

Number of Positions / Contacts per Port: 8P8C
