SPMK SPMK281-6 Rapid Pressure Gauge Calibrator ((0~6)MPa)

Measurement range

Measurement pressure:(0~6)MPa

Measurement accuracy: ±0.02% FS

Output range

Output pressure: (0~6)MPa

Measurement accuracy: ±0.02% FS, ±0.05% FS

Working medium: Air or Nitrogen

External standard device: Range is not greater than the built-in pressure standard module, the external standard device range (0~2.5MPa, 0~1MPa, 0~600kPa, 0~250kPa), ±0.02% FS

External pressure source: 7MPa (optional)

Dimensions: (500 × 490 × 580) mm

Weight: 70kg

Control stability: ≤0.003% full scale

Pressure output stabilization time: Continuous output of more than 5 mins

Minimum controllable fineness adjustment: 0.1kPa

Screen size: 7-inch touchscreen display

Pressure input connector: M20 × 1.5 or NPT/BSP Male optional

Pressure output connector: Five M20 × 1.5 or NPT/BSP Female optional

Working environment: Ambient temperature (0~50)°C; Relative humidity ≤90%

Power supply: 220VAC

Dimensions: (600 × 350 × 210) mm

Weight: 17kg

Datasheet
