Table size (mm): 230x1067 / 230x1246
T slots(Noxmm): 3x16
Table loading (kg): 200
X axis(table longitudinal move) travel (mm): 550 / 740
Y axis(table cross move)travel (mm): 300
Z axis(Quill move)travel (mm): 127
X/Y/Z axis rapid feed (mm/min): 5000
X/Y/Z axis servo motor (Kw): 1
Knee vertical travel (mm): 380
Ram travel (mm): 315
Distance from spindle to table (mm): 0-380
Milling head
Spindle speed: Standard 16 steps (rpm): 50Hz: 60-4500 / 60Hz: 80-5440
Optianal Variable: 65-4200
Spindle taper: R8 / ISO40 Standard:R8 / Optional:ISO40
Motor power (HP): 3HP
Head rotating Swiveling: 90°
Head rotating Tilting: 45°
CNC: KND / HD500 / GSK
Package size (cm): 165x190x246
G.W (kg): 1200
