Worktable
Dimensions (mm): 650x430
T-slot Sizes (mmxN): 14x3
Max Load (kg): 300
Machine range
X Axis Travel (mm): 580
Y Axis Travel (mm): 420
Z Axis Travel (mm): 520
Max distance from Spindle Nose to Worktable (mm): 620
Min distance from Spindle Nose to Worktable (mm): 100
Spindle
Taper: BT40
Speed (rpm): 10000
Main Motor Torque (Nm): 35.8
Main Motor Power (kW): 7.5/11
Feed
X/Y/Z Axis Rapid Traverse (m/min): 48/48/48
Feed Speed (m/min): 20
Tool Magazine
Type: mechanical arm
Stations (number): 20
Changing Time (s): 1.8
Positioning Accuracy
JISB6300 (mm): ±0.005/300
JB/T8771.4 (mm): 0.012
Repositioning Accuracy
JISB6300 (mm): ±0.003
JB/T8771.4 (mm): 0.008
Gerneral Power Capacity (KVA): 18
Air-supply Pressura (Mpa): 0.5-0.7
Dimensions & Weight
Footprint (mm): 2510x1980
Height (mm): 2411
Weight (kg): 3500
CNC System: FANUC
Standard Accessories: Three-axis Ball Screw, linear guide rail X axis, linear guide rail Y axis, linear guide rail Z axis, Stainless-steel Guideway Protection, Full Enclosue, Water Tank Chip Conveyors, Lubricating System, Pneumatic System, Air Gun, Heat Exchanger, FANUC CNC System, SIEMENS CNC System, Ethenet, BT40 20T Mechanical Arm Tool Magazine, BT40 10,000RPM Spindle
Optional Accessories: Chain-type Chip Conveyors, Scraper-type Chip Conveyors, Magnetic Chip Conveyors, FIYANG CNC System, Renishaw NC4 Tool Detection, Renishaw TS27R Tool Detection, Marpross ML75P Tool Detection, Marpross TS30 Tool Detection, Renishaw OMP60 Workpiece Detection, Marpross E83Wa Workpiece Detection, Hydraulic Monitor, Rotary Table, Air Conditioner, CE Standard
