Table size: 330x1370 (13"x54") / 330x1500 (13"x54")
Long travel: 840 / 1000
Cross travel: 368
Vertical travel: 450
T-slot No. and size: 3 x 16
Ram travel: 500
Distance from spindle nose to table surface: 0-450
Spindle hole taper: (Standard): ISo 40
Spindle travel: 127
Spindle speed: (standard): (shift gradel) 50Hz 65-4500 60Hz: 80-5440
(optional): (variable) 65-3750
Auto quill feed: (three steps): 0.04(0.0015"/0.08(0.003")/0.15(0.006") mm/revolution
Spindle motor: 2.25Kw/5HP
Head swivel: 90°
Head tilting: 45°
Dimension of package:
one miller per case: 1800x2016x2180
two miller per case: 1800x2200x2180
Weight (kg): 2300
