SMAC RD6320/1 Radial Drilling Machine "ZJ" Brand

Max drilling diameter(mm): 63

Distace between spindle axis and column(mm): Max: 2000

Min: 450

Distace spindle nose and working surface of base plate(mm): Max: 1600

Min: 400

Spindle travel(mm): 400

Spindle taper(NO.): 5#

Range of spindle speeds(r/min): 20-1600

Number of spindle speeds: 16

Range of spindle feeds(mm/r): 0.04-3.2

Number of spindle feeds: 16

Table size(mm): 630x800

Trave of spindle head(mm): 1550

Power of main motor(kW): 5.5

Net weight(kg): 7000

Overall dimensions (LxWxH)(mm): 3080x1250x3291
