Max. Drilling capacity (mm): 32
Distance Spindle axis to column generating line (mm): 300-700
Diameter of column (mm): 150
Spindle taper (mm): MT3
Spindle travel (mm): 150
Spindel speeds range (mm): 100-1600
Spindle speeds series: 8
Range of Spindle feeds (mm/r): 0.08, 0.14, 0.23
Spindle feed: 360
Max. Distance nose to working surface of base (mm): 275-680
Dimension of worktable (mm): 250x250x250
Dimension of base (mm): 1050x550x120
Overall Size (cm): 123x55x120
Power of main motor (W): 0.75
G.W/N.W: 475-380
Packing dimension (cm): 123x62x134
Standard Accessories: Box shape worktable, Taper sleeve, Tool releasing Wrench, Drift, Eyelet bolts
Optional Accessories: Quick instead chuck, Tapping chuck, Grease gun, Foot stand
