Table size (mm): 420 x 1800
Longitudinal travel X (mm): 1200/1180
Cross travel Y (mm): 360/350
Vertical travel Z (mm): 460/450
Feed speed steps: 18
Feed speed ranges
Longitudinal X (mm/min): 22.5-1180
Cross Y (mm/min): 22.5-1180
Vertical Z (mm/min): 8.6-420
Min. distance between spindle center to table (mm): 30-48
Spindle speed steps: 18
Spindle speed ranges (kW): 30-1500
Main motor power (kW): 11
Overall size (cm): 243 x 226 x 194
Net weight (kg): 5200
