Table size (mm): 320 x 1320
Longitudinal travel X (mm): 800/780
Cross travel Y (mm): 300/280
Vertical travel Z (mm): 410/400
Feed speed steps: 18
Feed speed ranges
Longitudinal X (mm/min): 15-750
Cross Y (mm/min): 15-750
Vertical Z (mm/min): 5.7-280
Min. distance between spindle center to table (mm): 235-535
Spindle speed steps: 18
Spindle speed ranges (kW): 30-1500
Main motor power (kW): 7.5
Overall size (cm): 232 x 179 x 172
Net weight (kg): 3300
