Skylark EFT-5K16 Electrical fast transient (0,25－5kV)

Open circuit output voltage:0.25－5kV ±5％

50Ω load output voltage: 0.125－2.5kV ±5％

Wave sharp of the pulse: 5/50ns，50Ω/1000Ωload

Rise time:

- 5ns ±30％，50Ω load

- 5ns ±30％，1000Ω load

Duration:

- 50ns ±30％，50Ω load

- 50ns －15/+100sn，1000Ω load

Impedance: 50Ω ±20％

Output polarity: Negative

Repetition frequency: 0.1－1200.0kHz ±10％

Burst duration Standard: 15ms@2.5kHz/5kHz,750μs@100kHz,250μs@300kHz

Burst duration Adjustable: Nos of pulse can adjust at 1-255. Burst duration=（pulse number-1）/repetition frequency

Burst period: 100－999ms

Burst mode: Synchronous or asynchronous

Synchronous phrase: Free set at 0－360° , resolution: 1°

Test function: IEC standard or set test mode freely (1000 groups)

Built-in coupling and decoupling network (3-phrase and 5 wires):

- AC: 3-phrase 380V,16A, 50/60Hz

- DC: 380V,16A (Max)

Coupling mode: L1,L2, L3, N,PE,freely setup

Coupling capacitors: L1,L2, L3, N,PE,freely setup

Environment requirements: Temperature:15°C－35°C; Humidity: 10%－75%

Power requirements: AC220±10％,50/60Hz, 300W

Dimension: AC220±10％,50/60Hz, 300W

Weight: About 25kg
