Skylark CDN-5402 Surge coupling/decoupling network

Surge test voltage: Up to 6kV (1.2/50us waveform)

Coupling mode: Wire to ground (common mode)

Coupling method: 90V gas discharge tube + 160Ω resistance/each wire, 4 wires at the same time-ground (common mode)

Surge injection interface: 4mm socket

Test product interface: 4mm socket/shortcut terminal block

Terminal layout:

- 4 wires (the first pair of wires L1-L2, the second pair of wires L3-L4)

- 2-wire (L1, L2 in parallel, L3+L4 in parallel)

Data transfer rate: 100MBit/s

Operating Voltage: Max 50V DC

Working current: Maximum 1A

Dimensions: 257mm×168mm×355mm

weight: About 10kg

Use environment: Temperature: 10℃～35℃, relative humidity: 30%～60%
