Silicon Labs C8051F302-GM 8-bit Microcontrollers - MCU 8051 25 MHz 8 kB 8-bit MCU

Core: 8051

Width: 3 mm

Height: 0.88 mm

Length: 3 mm

Unit Weight: 24.090 mg

Data RAM Size: 256 B

Data ROM Size: 128 B

Data ROM Type: Flash

ADC Resolution: 8 bit

Data Bus Width: 8 bit

Interface Type: I2C, SMBus, UART

Mounting Style: SMD/SMT

Number of I/Os: 8 I/O

Processor Series: C8051

Program Memory Size: 8 kB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 2.7 V

Number of ADC Channels: 8 Channel

Maximum Clock Frequency: 25 MHz

Number of Timers/Counters: 3 Timer

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
