Sigma Electronics SHV2-5105A Vertical Balancing Machine (500 ~ 1,500 rpm; ø500mm; 3kW)

Workpiece

Max. Mass: 5kg

Max. Diameter: ø500mm

Mechanical unit

Motor: AC servo motor, 3.0kW

Chucking Adapter: Manual fitting with nuts with key

Balancing speed: 500 to 1,500 min-1

Bearing support system: Semi-hard type

Safety Cover: Double swing door with LS -optional

Vibration sensor: Optical contactless displacement sensor

Measuring unit

Balancing plane: 1 and 2 plane

Balancing method: Fixed-speed measuring

Eccentricity correction: Included

Min. Achievable Unbalance: 1.0 um

Graphic display: 5.7" TFT color LCD with touch screen

Min. unbalance indication:

Correction: 0.01mg *selecting from mg, g, kg

Unbalance: 0.01mg•mm *selecting from mm,cm

Indication mode: Polar coordinates and (3 to 24) components of unbalance vector (add or remove of unbalance correction masses are selectable)

No. of stored work data: 50 data (No limitation when use with USB memory)

Judgment of measured result: Judgment with set limit value

Data transfer: Measured data can be transferred to PC or stored USB cable

Others

Power supply: 3 phase 200V ±10%

Dimensions: 600(W) x 1100(L) x 1680(H)mm

Mass: Approx. 500kg
