SIEMENS 6ES7510-1DK03-0AB0 S7-1500 Controller

Configuration control

via dataset: Yes

Control elements

Mode selector switch: 1

Supply voltage

Rated value (DC): 24 V

permissible range, lower limit (DC): 19.2 V

permissible range, upper limit (DC): 28.8 V

Reverse polarity protection: Yes

Mains buffering

Mains/voltage failure stored energy time: 10 ms

Input current

Current consumption (rated value): 0.51 A

Current consumption, max.: 0.7 A

Inrush current, max.: 1.34 A; Rated value

I²t: 0.3 A²·s

Power

Infeed power to the backplane bus: 8.05 W

Power loss

Power loss, typ.: 3.5 W

Memory

Number of slots for SIMATIC memory card: 1

SIMATIC memory card required: Yes

Work memory

integrated (for program): 200 kbyte

integrated (for data): 1 Mbyte

Load memory

Plug-in (SIMATIC Memory Card), max.: 32 Gbyte

CPU processing times

for bit operations, typ.: 25 ns

for word operations, typ.: 32 ns

for fixed point arithmetic, typ.: 42 ns

for floating point arithmetic, typ.: 170 ns
