Switch: without
Nominal width: DN 32..50
Process connection: female thread G 1 1/4..G 2 (further process connections available on request)
Display range: 2..220 l/min for details see table "Ranges"
Qmax.: to 250 l/min
Tolerance: ±5 % of the full scale value plus viscosity variation
Pressure resistance: PN 200 bar
Media temperature: -20..+120 °C
Ambient temperature: -20..+70 °C
Media: water, oils (gases and aggressive media available on request)
Electrical data: none
Materials medium-contact
Brass construction: CW614N nickelled, CW614N, 1.4310, hard ferrite, DN 32..40: NBR
Stainless steel construction: 1.4571, 1.4404, 1.4310, hard ferrite PTFE-coated, DN 32..40: FKM
Non-mediumcontact materials: CW614N nickelled, PC
Weight: see table "Dimensions and weights"
Installation location
Standard: horizontal inwards flow from the left; other installation positions are possible; the installation position affects the display range.
