Senseca GHTU-SHUT-MP Humidity and Temperature Transducer (0~100 % RH, 40 ~120 °C, absorption hat / weather protection)

Measuring ranges:

Humidity: 0.0 ... 100.0 % RH (temperature compensated)

Temperature: -40.0 ... +120.0 °C or -40.0 ... +248 °F

Recommended humidity range: 20.0 ... 80.0 % RH 

Display options: with option UNI an alternative display unit can be shown  instead of the humidity measuring value. The unit selection  will be done via keyboard.

Wet bulb temperature: -27.0 ... +60.0 °C

Dewpoint temperature: -40.0 ... +60.0 °C

Enthalpy: -25.0 ... +999.9 kJ/kg

Atmospheric humidity: 0.0 ... 640.0 g/kg

Absolute humidity: 0.0 ... 200.0 g/m³

Accuracy(at 25 °C and in recommended range)

Display:

humidity: ±2.5 % RH

temperature: ±0.4 % of measuring value ±0.2 °C

Output signal:

humidity ±0.2 % FS, 

temperature ±0.2 % FS

Temperature compensation: automatically

Auxiliary energy: 12 ... 30 VDC or 18 ... 30 VDC (for output: 0-10 V)

Reverse voltage protection: 50 V, permanently

Perm. impedance (at 4-20 mA): RA [Ω] ≤ (UV [V] - 12V) / 0.02 A

Permissible load (at 0-1(10)V): RL [Ω] > 3000 Ω

Display: approx. 10 mm high, 4-digit LCD-display, alternating humidity and temperature display

Working temperature: -25 ... +50 °C (electronics)

Sensor head and tube: -40 ... +100 °C - for short time up to 120 °C

Storage temperature: -25 ... +70 °C

Relative humidity (electronic): 0 ... 95 % RH (non condensing); If there is a risk of condensation due to temperature changes, please use our encapsulated or lacquered types (optionally available).

Housing: ABS (IP65)

Sensor tube: tube 14 mm Ø, with screw-type protection cap

Design type SHUT: heat absorption hat / weather protection shield 

Application: The heat absorption hat is especially designed  for measurements in the open air. The measuring results that  can be achieved will not be infl uenced by either sun or rain.

Design: Heat absorption hat made of plastic, Ø 110 mm,  approx. 140 mm high. Additionally equipped with a stainless  steel base for wall mounting, with 3 fi xing holes for screws with  a max. shaft Ø of 5 mm. Large projection approx. 160 mm

Electric connection: elbow-type plug acc. to EN 175301-803/A (IP65)

Mounting: 4 housing holes for wall mounting or by means of plastic tube  clamps for duct mounting

Functions: min-/max-value memory, offset and slope adjustable,  output signal scaleable
