Lightning detection: Triggered by cloud-to-ground, intracloud and cloud-cloud lightning.
Lightning events detected:
Charged Precipitation (Prewarning)
Strong Electric Field (Prewarning)
Severe Storm
Measuring range: 35 km (Default) / 83 km (Optional)
Range resolution: 1 m
Range accuracy:
For flashes within 20 km: ±5 km
For flashes within 83 km: ±10 km
Detection efficiency:
For flashes within 35 km:
97% for a single lightning flash
99.9% for storm with 2 lightning flashes
For flashes within 56 km:
95% for a single lightning flash
99% for storm with 2 lightning flashes
99.9% for storm with 3 lightning flashes
False alarm rate:
For flashes within 35 km: <1%
For flashes within 83 km: <2%
Maximum flash rate: 120 flashes per minute
Flash latency: 2 seconds
Output: RS422, Relays
Power supply: 9…36 Vdc
Power consumption: 2 W typical, up to 50 W with Extreme Heater Module
Connection: M12 connectors (Stainless Steel)
Operating temperature: -20...+40 °C
Relative humidity: 0...100% RH
Protection rating: IP66
Material:
Housing: Aluminium
Sphere antenna: Stainless Steel
Insulators: PTFE/Acrylic
Weight: Approx. 4.3 kg
See Datasheet for suitable figuration.
