Sensata Technologies - Crydom D1D100K Controller SOLID STATE RELAY

Width: 44.5 mm

Height: 26.4 mm

Length: 57.3 mm

IP Rating: IP00

Output Type: MOSFET

Unit Weight: 95.585 g

Input Current: 10 mA to 15 mA

Mounting Style: Panel Mount

Termination Style: Screw

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 100 A

Load Voltage Rating: 1 VDC to 100 VDC

On Resistance - Max: 5 mOhms

Control Voltage Range: 3 VDC to 32 VDC

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C

Input to Output Isolation Method: 3750 VRMS
