Sensata Technologies - Crydom CWD2425H Indicator SOLID STATE RELAY 24-280 VAC

Width: 44.5 mm

Height: 30.9 mm

Length: 58.8 mm

IP Rating: IP20

Output Type: SCR

Unit Weight: 86.500 g

REACH - SVHC: Details

Input Current: 10 mA to 15 mA

Mounting Style: Panel Mount

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 25 A

Load Voltage Rating: 24 VAC to 280 VAC

Control Voltage Range: 3 VDC to 32 VDC

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
